9) Technical characteristics
Designation Characteristics
la cir tcelE
Backup Permanent backup of all parameters in case of mains
failure. Automatic resetting of receiver clocks to correct time
after mains restoration.
Time base Quartz, accuracy 0.1 seconds per day between 20 and 25°.
Power supply 115 or 230 V AC ± 10% 50/60 Hz or 24 V DC, or 36/72VDC
(depending on the model).
Maximum
consumption
25W, 50W for the model 36/72VDC.
Mains terminals Cross section 1.5², maximum baring 6 mm.
Earth terminal Rack: rigid or flexible cable with end piece with cross
section 1² to 1.5²
Wall-mounted: rigid wire 1² to 1.5² bared 6 mm.
Other terminals Cross section 1.5² maximum, bared 6 mm.
Electrical isolation Class 1.
Mains power supply
system
TT or TN system.
sya leR
Control circuit (relay)
isolation
Galvanic isolation.
Circuit operating
voltage
Either SELV* or LV** with common phase (230 V maximum
between the 2 circuits).
Relay breaking
capacity
240V AC 1A.
Usefulness of
indicator light (of each
circuit)
1) Lit when contact closed.
2) Used to indicate the current circuit programming.
Types of relays Double-throw (SPDT) on circuit 3.
Normally open (SPNO) on circuits 1 and 2.
