11.3 Set a 24V TBT output
The 24V must be connected to the terminals 14 and 15.
Switch on the SIGMA.
Enter the technician menu (see page 14).
Enter the “Time outputs” menu.
Use the navigation keys to select :
TBT24V.
Caution : this output is protected ; if the current is too high, an alarm will go
off and the output will stop supplying 24V.
32
Impuls 01: TBT24V ú
STOP ok
