DUCTED REVERSE CYCLE REFRIGERATED AIR CONDITIONING
Page 9
Dimensions & Clearances
INDOOR UNIT CLEARANCES
Clearance Options for Maintenance
(Mandatory) Fan Removal Clearances Options
Unit
A A + B C D
B007HD 500 500 500 450
B009HD 500 500 500 450
B012HD 500 850 850 450
B015HD 500 850 850 450
B016HD 500 850 850 450
B019HD 500 850 850 450
