15.3 Digital Outputs
The Operation mode Digital output 1 530 and the relay output with the parameter
Operation mode Digital output 3 532 link the digital outputs to various func
tions.
The selection
of the functions depends on the parameterized configuration. The use
of the multifunctional output MFO1 as a digital output demands selection of an Oper-
ation mode 550 and linking via parameter Digital operation MFO1 554.
Operation mode 530,532,554
Function
0 - Off Digital output is switched off.
1 - Ready or Standby Signal
Frequency inverter is initialized and on stand-by
or in operation.
2 - Run Signal
Signal enable STO (S1IND/STOA and
S7IND/STOB) and a start command are present,
output frequency available.
3 - Error Signal
Message is displayed via the parameter Current
error 259 or Warnings 269.
4 - Setting Frequency
The Stator frequency 210 is higher than the
parameterized Setting frequency 510
5 -
Reference Frequency
reached
The Actual frequency 241 of the drive has
reached the Internal reference frequency 228.
6 -
Reference Percentage
Reached
The
Actual percentage
230
has reached the
Ref-
erence percentage 229.
7 - Ixt warning
The Warning Limit Short-Term Ixt 405 or Warn-
ing Limit Long-Term Ixt 406 has been reached.
8 -
Warning
Heat sink temperature
Max. heat sink temperature T
K
of 80 °C minus
the Warning Limit Heat Sink Temp. 407
reached.
9 -
Warning
Inside temperature
Max. inside temperature T
i
of 65 °C minus the
Warning Limit Inside Temp. 408 reached.
10 - Warning Motor Temperature
Warning behavior according to parameterized
Operation mode Motor temperature 570 at max.
motor temperature T
PTC
.
11 - Warning General
The message is displayed via parameter Warn-
ings 269.
12 - Warning overtemperature
The selected limit values Warning Limit Heat
Sink Temp. 407, Warning limit Inside Temp.
408 or the maximum motor temperature has
been exceeded.
13 - Mains Failure
Failure of the mains voltage and power regula-
tion active according to Operation Mode 670 for
the voltage controller.
14 -
Warning Motor Protect.
Switch
Parameterized Operation Mode 571 for the mo-
tor protection switch has triggered.
15 - Warning Current Limitation
A controller or the Operation Mode 573 of the
intelligent current limits limits the output current.
16 -
Controller Current Limit.
Long Term Ixt
The overload reserve for 60 s has been used up
and the output current is being limited.
17 -
Controller Current Limit.
Short Term Ixt
The overload reserve for 1 s has been used up
and the output current is being limited.
18 - Controller Current Limit. TK
Max. heat sink temperature TK reached, intelli-
gent current limits of Operation mode 573 ac-
tive.
19 -
Controller Current Limit.
Motor Temp.
Max. motor temperature reached, intelligent cur-
rent limits of Operation Mode 573 active.
20 - Comparator 1
The comparison according to the selected Op-
eration mode Comparator 1 540 is true.
21 - Comparator 2
The comparison according to the selected Op-
eration mode
Comparator
2
543 is true.
