BONFIGLIOLI ACTIVE Cube ACU 401-45

Error Environment
No.
Description
Unit
Display range
Chapter
367 Application Warning Status - A0000 … AFFFF
21.4
Positioning
470
Rotations
U
0.000 ... 1
⋅
10
6
12.6
Digital Outputs
537
Actual warning mask
-
AXXXXXXXX
15.3.8
627
Actual Appl. Warning Mask
-
AXXXX
15.3.9
Self-configuration
797 SET-UP Status - OK / NOK
8.5
22.2 Parameter Menu (PARA)
Inverter Data
No.
Description
Unit
Setting range
Chapter
0
Serial Number
-
Characters
9.1
1
Optional Modules
-
Characters
9.2
12
Inverter Software Version
-
Characters
9.3
15
Copyright
-
Characters
9.3
27 Set password - 0 ... 999
9.4
28 Control level - 1 ... 3
9.5
29 User Name - 32 characters
9.6
30 Configuration - Selection
9.7
33 Language - Selection
9.8
34
Program(ming)
-
0 ... 9999
9.9
37
Start Positioning of Axle
-
Selection
12.6.2
Fan
39 Switch-on temperature deg.C 0 ... 60
18.2
Shot effect function
48
Reference frequency
-
Selection
18.8
Digital inputs
49
Handshake Traverse Function
-
Selection
15.4.10
58
Technology Controller Release
-
Selection
17.3
62
Frequency Motorpoti Up
-
Selection
15.4.9
63
Frequency Motorpoti Down
-
Selection
15.4.9
66
Fixed frequency change-over 1
-
Selection
15.4.8
67
Fixed frequency change-over 2
-
Selection
15.4.8
68 Start clockwise - Selection
15.4.1
69 Start anticlockwise - Selection
15.4.1
70 Data set change-over 1 - Selection
15.4.7
71 Data set change-over 2 - Selection
15.4.7
72
Percent Motorpoti Up
-
Selection
15.4.9
73
Percent Motorpoti Down
-
Selection
15.4.9
75
Fixed perc. value change-over 1
-
Selection
15.4.8
76
Fixed perc. value change-over 2
-
Selection
15.4.8
83
Timer 1
-
Selection
15.4.4
84
Timer 2
-
Selection
15.4.4
87 Start 3-wire control - Selection
15.4.2
103 Error Acknowledgment - Selection
15.4.3
164 n-/M Control Change-Over - Selection
15.4.6
183 External error Selection
15.4.12
Digital inputs
204
Therm. Contact
-
Selection
15.4.5
278 Operating Instructions ACU 06/13
