22 Parameter List
The parameter list is structured according to the menu branches of the control unit.
The parameters are listed in ascending numerical order. A headline (shaded) can
appear several times, i.e. a subject area may be listed at different places in the table.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SETUP routine.
This parameter cannot be written when the frequency inverter is in operation.
I
FIN,
U
FIN,
P
FIN
:
rated values of the frequency inverter, o: overload capacity of frequency inverter
(201) value for ACU201 devices
(401) value for ACU401 devices
ACU201 devices: U
dmax
=387,5 V, ACU401 devices: U
dmax
=770 V
At the control unit KP500 parameter numbers > 999 are displayed hexadecimal at the
leading digit (999, A00 … B5 … C66).
22.1 Actual Value Menu (VAL)
Actual Values of the Machine
No.
Description
Unit
Display range
Chapter
210 Stator Frequency Hz 0.00 ... 999.99
19.2
211 R.m.s Current A 0.0 ... I
max
19.2
212 Output Voltage V 0.0 ... U
FIN
19.2
213
Active Power
kW
0.0 ... P
max
19.2
214
Active Current
A
0.0 ... I
max
19.2
215
Isd
A
0.0 ... I
max
19.2
216
Isq
A
0.0 ... I
max
19.2
217
Encoder 1 Frequency
Hz
0.00 ... 999.99
19.2
218
Encoder 1 Speed
1/min
0 ... 60000
19.2
221 Slip Frequency Hz 0.0 ... 999.99
19.2
Actual Values of the Frequency Inverter
222
DC-Link Voltage
V
0.0 ... U
dmax
-25
19.1
223
Modulation
%
0 ... 100
19.1
Actual Values of the Machine
224 Torque Nm ± 9999.9
19.2
225
Rotor Flux
%
0 ... 100
19.2
226
Winding Temperature
deg.C
0 ... 999
19.2
227
Act. Rotor Time Constant
ms
0 ... τ
max
19.2
Actual Values of the Frequency Inverter
228 Internal ref. frequency Hz 0.00 ... f
max
19.1
229 Reference percentage %
± 300.00
19.1
230
Actual percentage value
%
± 300.00
19.1
Actual value memory
231 Peak value long-term Ixt % 0.00 ... 100.00
19.3
232 Peak value short-term Ixt % 0.00 ... 100.00
19.3
