Bongioanni Multidea Evo 60 - Technical Data

TECHNICAL DATA
DESCRIPTION
Multidea Evo - Multidea Evo M
60 100 115
Fuel
G20 (20 mbar) - G30(28-30 mbar) - G31 (37 mbar)
Country(s) of destination
EU
Appliance category
II2H3B/P
Type of appliance
B23P, C13, C33, C43, C53, C63, C83
Max. nominal heating output (Qn)
55.1 94 107 kW
Min. heating output (Qmin)
7.0 11.8 15 kW
Nominal heating output (80-60°C)
53.2 91.2 104.0 kW
Energy saving heating output (80-60°C)
6.7 11.3 14.5 kW
Nominal heating output (50-30°C)
57.5 98.5 112.5 kW
Energy saving heating output (50-30°C)
7.5 12.6 16.1 kW
EFFICIENCY
Useful efficiency at max. Pn (80-60°C)
96.6 97.0 97.2 %
Useful efficiency at min. Pn (80-60°C)
95.8 96.0 96.5 %
Useful efficiency at max. Pn (50-30°C)
104.3 104.8 105.1 %
Useful efficiency at min. Pn (50-30°C)
107.2 106.8 107.0
%
Useful efficiency at 30% load (return 30°C)
108.6 108.0 108.3 %
Max. gas consumption (G20)
5.83 9.95 11.32
m
3
/h
Min. gas consumption (G20)
0.74 1.25 1.59
m
3
/h
Max. gas consumption (G30)
4.35 7.41 8.44 kg/h
Min. gas consumption (G30)
0.55 0.93 1.18 kg/h
Max. gas consumption (G31)
4.28 7.30 8.31 kg/h
Min. gas consumption (G31)
0.54 0.92 1.17 kg/h
EMISSIONS
Flue temperature (80-60°C) at Qn
65 - 75
°C
Flue temperature (80-60°C) at Qmin
55 - 60 °C
Flue temperature (50-30°C) max/min
40 - 45 °C
Mass flue flow rate at Qn
0.0259 0.0450 0.0498 kg/sec
Mass flue flow rate at Qmin
0.0035 0.0059 0.0073 kg/sec
Mass air flow rate at Qn
0.0247 0.0430 0.0476 kg/sec
Mass air flow rate at Qmin
0.0033 0.0056 0.0069 kg/sec
Max. condensate production min/max
2.2/8.6 3.7/14.6 5.3/16.7 l/h
Max/min CO2 (G20)
9.3/8.8 9.1/8.7 9.4/9.0 %
Max/min CO2 (G30)
11.8/11.2 11.8/11.6 11.8/10.6 %
Max/min CO2 (G31)
10.1/9.6 9.9/9.4 10.2/9.4 %
Weighted CO
18 13 11 mg/kWh
Weighted NOx
64 28 30
mg/kWh
NOx CLASS
5
ELECTRICAL DATA
Max. electrical absorption Multidea Evo
165 415 595 W
Max. electrical absorption Multidea Evo M
103 335 680 W
Power supply voltage
230~50
V~Hz
Protection rating
IPX4D
BOILER
Max. operating pressure
6 bar
Max. operating temperature
90 °C
Boiler water content
5.5 8.0 8.7 l
Residualheatatnominal∆t(20°C)
110 130 580 mbar
ΔTMaximumsupply/return
35
WaterflowrateatnominalΔT(20°C)
2.29 3.92 4.47
m
3
/h
FLUE EXHAUST
Flue exhaust/air inlet fitting ø
80/80 100/80 100/80 mm
Max. length of cond. drain 80/125
5 5 3 m
Max. length of separate pipes 80/80
19 17 10,5
m
Residual air/flue head available
117 348 270 Pa
BLOWER
Speed at nominal heating capacity G20
5700 7200 7300 rpm
Speed at minimum heating capacity G20
1250 1450 1600 rpm
Speed at nominal heating capacity G30
5100 6100 6500 rpm
Speed at minimum heating capacity G30
1150 1250 1450 rpm
Speed at nominal heating capacity G31
5700 7000 7500 rpm
Speed at minimum heating capacity G31
1250 1400 1600 rpm
Speed at ignition heating capacity G20
3500 2850 3350 rpm
Speed at ignition heating capacity G30-G31
5100-4800 3200-3300 3700-3900 rpm
DIMENSIONS and WEIGHTS
Width
600 mm
Depth
480 480 560 mm
Height
900 mm
Weight
68 88 98 kg
