Bongioanni Multidea Evo 60 - Boiler Ignition

BOILER IGNITION
To start up the boiler:
- Ensure that a jumper is wired in or that an on-demand room
thermostat is set between terminals 7 and 8. The boiler will not work
without these conditions.
MANUAL TEST function
This procedure enables the user to override a heating cycle, with
settable power, for a maximum duration of 15 minutes
78
7 8
Room
Thermostat
230Vac
43 44
43 44
Room
Thermostat
24Vac
Key to
press
Description Display
F
A
to display the MENU screens
to enter the TECHNICIAN menu, which requires
entry of the PASSWORD
date
OUTSIDE
7
o
C
69
o
0.0
OFF OFF
time
MENU
USER
TECHNICIAN
A
a
A
To check the blower speed, at the maximum and/or minimum flow rate, proceed as described in the next paragraph
(BOILER IGNITION and MANUAL TEST function).
After setting the maximum and/or minimum boiler output, press:
-
to return to “3.Manual Test”
-
B
twice to select “1.Boiler information”
-
C
to enter the Diagnostics screen
-
D
ten times, to select “11. Blower Speed".
Check that this value corresponds to the value stated in the table above.
- Press
to return to the “Diagnostics” screen and repeat “3.Manual Test” for the other output setting.
- 47 -
INSTALLATION
