Bonnet Equator 6 Series User Manual

Page 21 3BE390691NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
- Grease the motor shaft with Biolub code: 360 109 grease (Special lubricant for the food industry) to
make fitting the rings easier.
- Assemble the ring with the gasket (assembly code : 145 587).
- Install the assembly on the driving shaft. Rotate the driving shaft before putting the turbine back in place.
Warning: - Check gasket/driving shaft co-axiality.
- Run the motors (before reassembling the turbines) to check proper positioning of the ring
and the gasket (they must not rotate together with the driving shaft).
- Reassembly : carry out the procedure in reverse order.
