Page 22 3BE390691NM – 10/10
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
9. FRONT LINE PARTS
Designation Code
Heating tangential fan 141614
Drive shaft gasket + wear ring 145587
Lighting socket sub-assembly + cable 147328
3 ways 3 x 10 L/min solenoid valve 147723
Gas valve subassembly without safety box 147772
Gas valve subassembly without safety box 147773
4 ways 4 x 10 L/min solenoid valve 147791
Bent 1500 mm lenght starting electrode 147811
Sub assembly - Gas valve without safety enclosure 148222
Additional card 170763
On / Off switch 300176
Snap-on pushbutton 300183
Reed switch 300676
Three-pole 230V 50/60 Hz contactor 25A / 32A 300697 / 300698
Three-pole 230V 50/60 Hz contactor 40A / 50A 300699 / 300700
Tree-pole 230V 50/60 HZ contactor 80A 300702
Anti-interference relay 300703
Anti-interference relay 300769
95°C thermostat 301048
60° C condenser thermostat 301065
Manual reseting 320°C thermostat + nut 301066
Pressure switch B1 55/41 301373
2 points PT 100 regulating sensor 301471
Circular heating element, round flange, 9KW diameter 340 302229
Circular heating element, round flange, 15KW diameter 500 302230
Circular heating element, round flange, 9KW diameter 430 302232
Diameter 430 inner flange of 12 kW circular heating resistance 302242
Axial fan 304194
16mf motor condensator 304259
Ventilation motor 304267
Centrifugal fan SP MVL 230V / 50Hz 304268
LN2 fixed centrifugal fan 7000rpm 304276
Reducing gear with center return spring, 85 degrees 305108
Green indicator 230/400V, complete 308334
Halogene bulb 308477
Lighting transformer BT 230V 50HZ 12V 308479
1A fast acting fuse 309335
Fuse 3.15 Amps 309407
Encoder 309411
Ribbon 309417
Fuse 6.3 x 32 T10 Amps SCHURTER 309506
Maxi UC relay card 309512
Led fascia card 309515
EEPROM for UC maxi 309519
5 position switch, 8 point connector + 2 wires 309521
3 position switch, 6 point connector 309522
Safety box 577DBC 310324
Heating resistance capacity + immersion heater gasket 366461
Lighting glass sheet gasket 366557
Door stop 366572
Synthetic filter 386087
