28/68 Transport and storage
Bosch Rexroth AG, A4VG Series 32, RE 92003-01-B/12.2015
6 Transport and storage
▶ Always observe the required ambient conditions for transport and storage, see
Chapter6.2 “Storing the axial piston unit” on page30.
Notes on unpacking can be found in Chapter7.1 “Unpacking”
on page32.
6.1 Transporting the axial piston unit
The following transportation options are available depending on the weight and
duration of transport:
• Transport by hand (chapter not relevant for this axial piston unit)
• Transporting with a lifting device (eye bolt or lifting strap)
Table 6: Dimensions and weights
Size 28 40 56 71 90 125 180
Weight kg 29 31 38 50 60 80 101
Width mm Dimensions vary by equipment. The values applicable for
your axial piston unit can be found in the installation
drawing (request if necessary).
Height mm
Depth mm
Weight may vary by equipment.
6.1.1 Transporting by hand
Axial piston units with a weight of up to 15kg can be transported manually for a
short time if necessary.
CAUTION. Danger from heavy loads.
Health hazard from carrying axial piston units.
▶ Use suitable lifting, lowering and moving methods.
▶ Wear your personal protective equipment (e.g., safety goggles, safety gloves,
suitable working clothes, safety shoes).
▶ Do not use sensitive attachments to transport the axial piston unit (e.g., sensors
or valves).
▶ Carefully place the axial piston unit on the seating to prevent it from being damaged.
6.1.2 Transporting with a lifting device
For transporting, the axial piston unit can be connected to a lifting device via an eye
bolt or a lifting strap.
The axial piston unit can be transported suspended from an eye bolt screwed into
the drive shaft as long as only outward (pulling) axial forces are applied.
▶ For all female threads, use a stud end from the same system of units and of the
correct size.
Dimensions and weights
Transport with eye bolt
