34/68 Installation
Bosch Rexroth AG, A4VG Series 32, RE 92003-01-B/12.2015
7.3 Installation position
The following installation positions are permissible. The piping layout shown
illustrates the basic layout.
Installation position “drive shaft upwards” (position 4 and 10):
With the installation position “shaft upwards”, you need the additional air bleed
port R
1
in the flange area for the sizes 71 to 180. This port is not provided in the
standard version and must be stated in plain text when ordering.
If filling the stroking chambers via X
1
to X
4
is not possible in the final installation
position, then this must be effected before installation, e.g. in installation position 2.
To prevent unexpected actuation and damage, the stroking chambers must be air
bled via the ports X
1
, X
2
, or X
3
, X
4
depending on the installation position.
