36/68 Installation
Bosch Rexroth AG, A4VG Series 32, RE 92003-01-B/12.2015
7.3.2 Above-reservoir installation
Above-reservoir installation means that the axial piston unit is installed above the
minimum fluid level of the reservoir.
Observe the maximum permissible suction height h
Smax
= 800mm. The
permissible suction heighth
S
is derived from the total pressure loss.
Recommendation for installation position 10 (drive shaft upward): A check valve in
the drain line (cracking pressure 0.5bar) can prevent the housing area from draining.
7
F
2
S
SB
h
t min
h
min
h
S max
F
1
T
1
R
T
2
X
2
, X
1
8
F
2
S
SB
h
t min
h
min
h
S max
F
1
T
1
T
2
9
T
1
T
2
S
F
2
SB
h
t min
h
min
h
S max
F
1
X
2
, X
1
10
R
F
2
R
1
T
1
T
2
0.5 bar
S
h
t min
h
min
h
S max
SB
F
1
X
3
, X
4
11
T
1
T
2
S
F
2
SB
h
t min
h
min
h
S max
F
1
X
3
12
T
1
T
2
S
F
2
SB
h
t min
h
min
h
S max
F
1
X
4
Fig. 11: Above-reservoir installation A4VG with installation position 7-12
T
1
, T
2
Highest drain port
h
t min
Minimum required immersion depth (200mm)
F
1
, F
2
Filling / air bleeding
h
min
Minimum required distance to reservoir
bottom (100mm)
R, R
1
Air bleeding
h
S max
Maximum permissible suction height (800mm)
S Suction port SB Baffle (baffle plate)
X
1
, X
2
Control pressure
X
3
, X
4
Stroking chamber pressure port
Ports F
1
and F
2
are part of the external piping and must be provided on the
customer side to make filling and air bleeding easier.
