AMC2 Modular
Controller
Installing | en 25
Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |
4.3 Opening the Case
Notice!
To open the AMC2-4W , first remove all pluggable connectors.
The AMC2-4W case consists of a top cover mounted with a two-
point snap-in closure on a chassis. To open the case, push down
the two snap-ins with a screwdriver, then swing the cover down.
Figureî4.3: Opening the AMC2 case
