Bosch AMC2 Series - Tamper Protection

44 en | Installing
AMC2 Modular
Controller
2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH
4.13 Tamper Protection
To protect the AMC2-4W against unauthorized access and so
prevent tampering with sensitive data, the AMC2-4W provides
an additional interface to connect external tamper contacts.
This interface is a potential-free 2-pin pluggable screw
connector marked with T. When not in use this tamper contact
should be shorted.
Figure4.16: Location of the tamper protection contact
