52 en | Operating
AMC2 Modular
Controller
2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH
6 Operating
Notice!
To build a UL listed configuration, refer to UL Requirements,
page 45
6.1 Status Display of the AMC2
The liquid crystal display delivers status information about the
AMC2-4W . Push the 'Dialog' button to switch between different
modes.
Figure6.1: Location of the ’Dialog’ button
