AVENAR panel 8000 | AVENAR panel 2000 |
AVENAR keypad 8000
Diagnostics | pt-BR 61
Bosch Sicherheitssysteme GmbH
Manual do utilizador
2023-08 | 8.0 | F.01U.378.877
Aviso!
The numbers before the module names indicate the slot of the module on the panel.
14.7 Network services
14.7.1 Routing table
To display routing information:
1. In the start menu, select Diagnósticos
2. Serviços de rede
3. Tabela de Routing
A table with routing information is displayed.
All networked nodes that can be reached via the node currently being operated and that are
recognized within the system network are displayed under Node.
CAN1 to USB1 designate the interfaces on the currently operated panel node. In this example,
it is the node 1 interfaces.
The type of interface on the panel node currently being operated is listed under interface.
The following interfaces can be designated:
– CAN 1 interface
– CAN 2 interface
– Ethernet 1 (IP multicast or UDP tunnel)
– Ethernet 2 (IP multicast or UDP tunnel)
– Ethernet 3 (IP multicast or UDP tunnel)
– Ethernet 4 (IP multicast or UDP tunnel)
– USB 1 interface
The number of nodes that need to be passed in order to reach the listed node is entered
under distance. For nodes that are directly reachable via IP multicast, the value is 1; for nodes
that are connected via other interfaces (e.g. CAN) to nodes reachable via IP multicast, the
value is increased in increments accordingly (e.g. connected via IP multicast + CAN1/CAN2,
value = 2).
A physical node number from 1 to 64 can be assigned to panels.
14.7.2 Consistency check
Inconsistencies between the network settings configured in FSP-5000-RPS and those set in
the panel controller are displayed under Diagnósticos - Serviços de rede -
Verif de consistência.
1. In the start menu, select Diagnósticos
2. Serviços de rede
3. Verif de consistência
Where inconsistencies are identifiable between the network settings saved in the panel
controller and those configured in FSP-5000-RPS, these are indicated. You can use the
arrow key on the display to alternate between displaying Problemas na configuração
actual: and Problemas esperados após o reinício:.
Problemas na configuração actual:
The table indicates inconsistencies between the network settings of the panel controller's
active configuration ("active") and the settings configured in RPS ("configured").
