1 689 979 792 2010-02-24| Robert Bosch GmbH
Symbols Used | BAT 121 | 11BAT 121 | 11 | 11
en
Contents 1. Symbols Used
Pictograms linked with the key words Danger, Warning
and Caution are warnings and always indicate an imme-
diate or potential hazard to the user.
Danger!
Immediate danger that could cause serious
personal injury or death.
Warning!
Potentially dangerous situation that could
cause serious personal injury or death.
Caution!
Potentially dangerous situation that could
cause personal injury or damage to property.
! Important – warns of a potentially hazardous situa-
tion in which the BAT 121, the test sample or other
object in the vicinity could be damaged.
In addition to these warnings, the following symbols are
also used:
i Info – In addition to these warnings, the following
symbols are also used.
¶ Single-step procedure – instructions for a procedure
that can be completed in just one step.
? Intermediate result – an intermediate r esult is
displayed during a procedure.
! Final result – the final result is displayed at the end
of the procedure.
1. Symbols Used 11
2. User information 12
2.1 Important notes 12
2.2 Safety instructions 12
2.3 Electromagnetic compatibility (EMC) 12
3. Equipment description 12
3.1 Scope of delivery 12
3.2 Optional accessories 12
3.3 BAT 121 12
3.4 Functions of the keys 13
3.5 Inserting paper in the printer module 13
4. What you should be aware of and
observe when testing a starter battery 14
4.1 General notes 14
4.2 Absolutely necessary entries 15
4.3 Important tips on testing batteries 15
4.4 Additional comments 15
5. Operation 16
5.1 Battery-Test 16
5.1.1 Parameter setting 16
5.1.2 Battery test evaluation 17
5.1.3 Notes on problems 17
5.2 Alternator-Test 17
5.2.1 Alternator test procedure 17
5.2.2 Hinweise bei Störungen 18
5.3 Voltmeter 18
5.4 Configuration 18
5.4.1 Contrast 18
5.4.2 Language 18
5.4.3 Dealer Address 18
5.4.4 Service 18
5.4.5 Acid Density 19
5.4.6 Date (only with clock module) 19
5.5 Last Test Result 19
6. Maintenance 1�
6.1 Cleaning 19
6.2 Service parts and parts subject to wear 19
6.3 Disposal 19
7. Technical data 1�
