Bosch CA - Motor and Pressure Data; PSC Motor Electrical and Pressure Drop Data

18 | Water side pressure drop CA Model
CA Model8733942456 (2016/04) Subject to change without prior notice
PSC Motor
Electrical Data Table - PSC Blower Motor
WATER SIDE PRESSURE DROP
MODELS
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/MAX
COMPRESSOR TOTAL UNIT PSC MOTOR COMPRESSOR SERVICE
QTY RLA LRA FLA MIN
CIRCUIT
AMPS
MAX
FUSE/
HACR
COLD WINDING
RESISTANCE (Ω)
RUN
CAPACITO
R (μF/V)
SINGLE
PHASE:
S-C
SINGLE
PHASE:
R-C
009
0
115/1/60 104/126 1 7.0 45.6 2.1 10.9 15 3.48 0.71 35/240
1 208-230/1/60 197/253 1 3.4 22.2 0.9 5.2 15 7.35 2.95 15/370
2 265-277/1/60 239/291 1 2.9 18.8 0.7 4.3 15 10.74 4.27 10/440
012
0
115/1/60 104/126 1 9.6 58.4 1.3 13.3 25 3.15 0.58 35/370
1 208-230/1/60 197/253 1 4.6 27.9 0.8 6.6 15 5.90 2.30 20/370
2 265-277/1/60 239/291 1 3.8 22.2 0.8 5.6 15 8.70 3.47 15/440
015
0
115/1/60 104/126 1 12.7 63.0 1.3 17.2 25 N/A N/A 40/370
1 208-230/1/60 197/253 1 5.6 29.0 0.8 7.8 15 5.45 2.31 25/440
2 265-277/1/60 239/291 1 4.6 20.0 0.8 6.6 15 7.39 3.58 15/440
018
1
208-230/1/60 197/253 1 7.4 33.0 0.8 10.1 15 3.05* 2.41* 35/370
2
265-277/1/60 239/291 1 6.0 28.0 0.8 8.3 15 2.57* 3.26* 35/440
* These values are reported at 167°F (75°C), not room temperature. All other resistance values must be measured with
compressor at room temperature. Resistance value tolerance +/- 7%.
Model GPM Pressure Drop (PSIG) Pressure Drop (ft of H2O)
009
1.3 0.98 2.25
1.5
1.26 2.91
2.0
2.11 4.87
2.5
3.16 7.29
3.0
4.39 10.13
012
1.5 1.26 2.91
2.0
2.11 4.87
2.5
3.16 7.29
3.0
4.39 10.1
4.0
7.36 17.0
015
2.5 1.08 2.50
3.0
1.50 3.47
3.5
1.98 4.58
4.0
2.52 5.82
5.0
3.77 8.70
018
2.5 1.08 2.50
3.0
1.50 3.47
4.0
2.52 5.82
5.0
3.77 8.70
6.0
5.24 12.1
