WIRING DIAGRAMS
Figure # 13
FAN MOTOR SPEED TABS - 4 POLE MOTORS
UNIT HI LO CAPPED CAPPED
009 BLU RED BLK ORG
012 ORG
BLU
BLK RED
015 BLK BLU ORG RED
018 BLK ORG BLU RED
FAN MOTOR SPEED TABS - 3 POLE MOTORS
UNIT HI LO CAPPED
009 BLU RED BLK 012
BLU
RED BLK
015 BLU RED BLK 018 BLK RED BLU
FOR REFERENCE ONLY Actual unit wiring may
vary from this example. Always refer to the wiring
diagram attached to the unit.
