24 en | Installing the DINION capture DINION capture 5000/7000
| 1.0 | 2012.01 Installation Manual Bosch Security Systems, Inc.
3.5 Making the Connections
The easiest way to connect the cables is as follows:
1. Bring the building connections through the surface cable
hole so that they hang clear.
2. Connect the BNC connector of the license plate camera
module to the video coax cable. For the DINION capture
7000, connect a video coax cable to the video output
cables for both the license plate camera (white cable) and
for the overview camera (red cable).
3. Connect the ferrule tipped power wires (red, black;
polarity independent) from the license plate camera to the
power supply connection.
4. In damp environments ensure that the connections are
sealed inside a junction box or a field wiring box with
NEMA 3 or IP55 protection level or better. Make the
connections inside the water tight compartment. After
connections are made, ensure that the watertight
compartment is tightly closed and cables and conduits are
properly sealed to prevent ingress of water.
3.6 Automatic Mode Switching
Automatic Mode Switching is a feature on the license plate
camera that automatically compensates for bright conditions.
Automatic Mode Switching, by default, operates by switching
from Mode 1 (Normal) to Mode 2 (FullSun) when the ambient
light levels rise above normal conditions (for example, bright
sunlight on the scene). Automatic Mode Switching is inactive by
default and requires setup to operate as desired.
In most conditions, Automatic Mode Switching may not be
necessary. Activate the switch only if the license plate camera
WARNING!
Before proceeding, disconnect the DINION capture from the
power supply. Ensure that the voltage of the unit matches the
voltage and type of the power supply being used.
