Bosch DINION 5000 - Color Submenu; (Overview Camera - DINION Capture 7000 Only)

DINION capture 5000/7000 Configuration | en 43
Bosch Security Systems, Inc. Installation Manual | 1.0 | 2012.01
4.5.6 Color submenu (Overview Camera - DINION
capture 7000 only)
Item Selection Description
White balance ATW,
AWBhold,
Manual
ATW - Auto tracking white balance
allows the camera to constantly adjust
for optimal color reproduction.
AWBhold - Puts the ATW on hold and
saves the color settings.
Manual - the Red, Green, and Blue gain
can be manually set to a desired
position.
Speed Fast,
Medium,
Slow
Adjusts the speed of the white balance
control loop.
Red gain -5 to +5
-50 to +50
ATW and AWBhold - adjusts the Red
gain to optimize the white point.
Manual - adjusts the Red gain.
Blue gain -5 to +5
-50 to +50
ATW and AWBhold - adjusts the B gain
to optimize the white point.
Manual - adjusts the Blue gain.
Green gain -50 to +50 Manual - adjusts the Green gain.
Saturation -15 to +5 Adjusts the color saturation. -15 gives a
monochrome image.
EXIT Returns to main menu.
