Bosch DINION 5000 - Dimensional Drawings; DINION capture 5000

52 en | DINION capture 5000/7000
| 1.0 | 2012.01 Installation Manual Bosch Security Systems, Inc.
A Dimensional Drawings
DINION capture 5000
Figure 1.1 DINION capture 5000 – Side View
Figure 1.2 DINION capture 5000 – Front View
452
(17.8)
340
(13.3)
263
(10.4)
mm
(in.)
154
(6.1)
139
(5.5)
307
(12.1)
mm
(in.)
