DINION capture 7000
Figure 1.3 DINION capture 7000 – Side View
Figure 1.4 DINION capture 7000 – Front View
mm
(in.)
459
(18.1)
350
(13.8)
263
(10.4)
322
(12.7)
mm
(in.)
269
(10.6)
16
(0.6)
94
(3.7)
139
(5.5)
307
(12.1)
