20 en | Preparing for an E2700 controller-drive tray installation DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
DE6600 drive tray – front view with bezel
!
92036-01
DE6600 drive tray – front view with bezel removed
92034-04
!
DE6600 drive tray – rear view
92056-07
!
2 3 4 5 6 11
1 Fan canisters
2 ESM A
3 ESM B
4 Expansion port SFF-8088 connectors (IN)
5 Expansion port SFF-8088 connector (OUT)
6 Power canisters
