MON.B Live
CVBS: 1 Vpp, 75 ohm, BNC
Resolution (MON.B) CVBS (PAL): 704x576
CVBS (NTSC): 704x480
Audio
Inputs 4-ch RCA (for 4/8/16 channel), 200 to 3000 mV,
10 kOhm (RCA)
Output Mono RCA, 200 to 3000 mV, 5 kOhm (RCA)
MIC input Mono talk input RCA, 200 to 3000 mV, 10 kOhm (RCA)
Compression G.711A
Sample rate 8 kHz per channel
Bit rate 8-bit
Control
RS485 PTZ control port
Output signals according to RS485, max. signal voltage -5
to +5 V
RS232 PTZ control port interface
Output signals according to EIA/TIA-232-F, max input
voltage ±10 V
Supported protocols Pelco P and D (over RS-485)
Bosch OSRD (over RS-485 or RS-232)
Alarms
Inputs 16 inputs configurable NO/NC, max. input voltage 5 VDC
Outputs 3 relay outputs, configurable NO/NC
Relay contact Max. rated, 30 VDC, 2 A continuous or 125 VAC, 1 A
(activated)
Connectors
Video inputs 4, 8 or 16 BNC
Monitor outputs 1 VGA D-SUB
1 HDMI
2 channel BNC (CVBS)
Alarm inputs 16 screw terminal inputs, cable diameter AWG26‑16
(0.13–1.5 mm)
DIVAR 3000/5000 Digital Video
Recorder
Technical specifications | en 147
