Control
RS485 PTZ control port
Output signals according to RS485, max. signal voltage -5
to +5 V
RS232 PTZ control port interface
Output signals according to EIA/TIA-232-F, max input
voltage ±10 V
Supported protocols Pelco P and D (over RS-485)
Bosch OSRD (over RS-485 or RS-232)
Alarms
Inputs 16 inputs configurable NO/NC, max. input voltage 5 VDC
Outputs 5 relay outputs, configurable NO/NC, plus one controllable
12 VDC port
Relay Max. rated, 30 VDC, 2 A continuous or 125 VAC, 1 A
(activated)
Connectors
Video inputs 4, 8 or 16 BNC
Video outputs (loop through) 4 or 8 BNC (for 4 and 8 channel units)
1 x 25-pin D-type for 16 channel unit (connector cable
supplied)
Monitor outputs 1 VGA D-SUB
1 HDMI
2 channel BNC (CVBS)
Alarm inputs 16 screw terminal inputs, cable diameter AWG26‑16
(0.13–1.5 mm)
Alarm outputs 5 screw terminal outputs, cable diameter AWG26‑16
(0.13–1.5 mm)
1 controllable 12 VDC screw terminal output
Audio inputs 4 RCA
Audio outputs 1 RCA
Audio bidirectional (MIC) 1 RCA for talk input or output
Ethernet RJ45, 10/100/1000Base-T according to IEEE802.3
Intuikey keyboard (KBD Digital
or KBD Universal)
Conforms to RS485, max. signal voltage ±12 V, power
supply to keyboard 11 to 12.6 VDC at max. 400 mA
RS485 Screw terminal output
RS232 DB9 male, 9-pin D-connector
DIVAR 3000/5000 Digital Video
Recorder
Technical specifications | en 151
