3.1.1 Maximum cable length for connecting
interpreters desks LBB 3222/04
The maximum length of the cables to connect the
interpreters desks to the Integrus transmitter depends
on the number of interpreters desks. A leader cable
connects the first interpreters desk to the transmitter.
An extension cable may be needed between the inter-
preters desks. The table below shows the maximum
extension cable length (additional to the standard 3 m
cable) that can be used with different numbers of inter-
preters desks.
INTEGRUS | Installation and User Instructions | Connecting to an Integrus transmitter en | 9
Bosch Security Systems | 2005-04 | 9922 141 70164en
Number of interpreters desks LBB 3222/04 2 4 6 8 10 12
Additional leader cable length between meter 100 50 35 15 5 0
first interpreter desk and transmitter
Additional extension cable lengths meter 34 8 2.9 2.4 1.8 1
between interpreters desks
Number of interpreters desks LBB 3222/04 2 4 6 8 10 12
Additional leader cable length between feet 328 164 115 49 16 0
first interpreter desk and transmitter
Additional extension cable lengths feet 112 26 9.5 7.9 6.0 3.3
between interpreters desks
