Any time the spring adjustment nuts
are used to adjust the height of the top
crimper shaft, check the drive gears for
backlash. Backlash will cause improper
crimper alighment.
1. Disconnect and lockout the main power
while performing this procedure.
2. Access the drive gears and loosen the
seven hexhead screws in the upper
gear (3).
3. Turn the front half of the top gear
forward and hold it firmly while re-
tightening the 7 hexhead screws.
4. Replace the guarding.
3
