4.7 Parameter Denitions

PARAMETER DEFINITION

Accel Rate (sec) This is the time required for the wrapper to go from a stopped position

to 600 packages per minute�

Accum Hi Speed Ratio (%) This is the ratio of the feeder accumulator belt high speed to the wrap-

per speed�

Accum High Speed Delay (mm) This is a delay added to prevent the feeder accumulator belt from going

to high speed as soon as the accumulator eye is blocked�

Accum Low Speed Delay (mm) This is a delay added to prevent the feeder accumulator belt from going

to low speed as soon as the accumulator eye is unblocked�

Accum Low Speed Ratio (%) This is the ratio of the feeder accumulator belt low speed to the wrap-

per speed�

Angle Off Discharge Reject (deg) This is the position in a cycle where the discharge reject air blast stops�

Angle Off Generic 1 (or 2) Reject (deg) This is the position in a cycle where the generic reject eye stops check-

ing for the reject condition�

Angle Off Infeed Reject (deg) This is the position in a cycle where the infeed reject air blast stops�

Angle Off Long Product Reject (deg) This is the position in a cycle where the long product reject eye stops

checking for a long product�

Angle Off NGNS (deg) This is the position in a cycle where the missing product eye stops

checking for a product�

Angle Off NPNP (deg) This is the position in a cycle where the missing product eye stops

checking for a product�

Angle Off Pulse X (deg) This is the position in a cycle where pulse X ends�

Angle Off Reject Verify (deg) This is the position in a cycle where the verication eye stops checking

for a product�

Angle Off Short Product Reject (deg) This is the position in a cycle where the short product reject eye stops

checking for a short product�

Angle Off Tucker (deg) This is the position in a cycle where the air tucker stops making a tuck

in the package�

Angle Off Uncut Reject (deg) This is the position in a cycle where the uncut eye stops checking for an

uncut package�

Angle Off Window Stop This is the position in a cycle where the stop window ends�

Angle On Discharge Reject (deg) This is the position in a cycle where the discharge reject air blast starts�

Angle On Generic 1 (or 2) Reject (deg) This is the position in a cycle where the generic reject eye starts check-

ing for the reject condition�

Angle On Infeed Reject (deg) This is the position in a cycle where the infeed reject air blast starts�

Angle On Long Product Reject (deg) This is the position in a cycle where the long product reject eye starts

checking for a long product�

Angle On NGNS (deg) This is the position in a cycle where the No Gap eye starts to check for a

product�

Angle On NPNP (deg) This is the position in a cycle where the missing product eye starts to

check for a product�
