1.2 Machine Specications
1.2.1 Electrical
The standard wrapper’s electrical requirements are as
follows:
• 230 VAC ±10%, 3 phase, 50/60 cycle
• Dedicated line from service entry
• Green wire tied directly to earth ground at service
entry
• No other equipment may use the ground wire
There are several ways that the machine can be
connected to the power source. Consult a qualied
electrician to make this decision�
1.2.2 Air Supply
The wrapper requires 6 bar, 80PSI minimum�
1.2.3 Weight
The weight of the machine, including its standard
features, is approximately 4000 pounds without the
infeed�
1.2.4 Noise Level
The noise generated by the machine when it is running
is less than 80 decibels�
1.2.5 Speed
The speed at which the wrapper can wrap product
depends in part on the type and diameter of the
crimper�
• Maximum 1-up (1 crimper per shaft) capacity is
150 packages per minute�
• Maximum 2-up (2 crimpers per shaft) capacity is
250 packages per minute�
1.2.6 Maximum Film Size
The maximum reel diameter is 400 mm; the maximum
reel weight is 35 kgs, and the maximum lm width is
650 mm�
1.2.7 Max Min Package Length
Crimper Dia� Length Max
# Crimpers Range Height
100mm 1 up 140-310mm 45mm
(3�9”) (5�5”-12�2”) (1�75”)
100mm 2 up 85-155mm 45mm
(3�9”) (3�35”-6�1”) (1�75”)
120mm 1 up 170-375mm 65mm
(4�7”) (6�7”-14�75”) (2�5”)
120mm 2up 90-185mm 65mm
(4�7”) (3�5”-7�25”) (2�5”)
150mm 1up 200-470mm 95mm
(5�9”) (8�25”-18�5”) (3�75”)
150mm 2up 110-235mm 95mm
(5�9”) (4�3”-9�25”) (3�75”)
180mm 1up 250-565mm 115mm
(7�0”) (9�8”-22�25”) (4�5”)
180mm 2up 130-280mm 115mm
(7�0”) (5�1”-11�1”) (4�5”)
1.2.8 Dimensions
Dimensions given are approximate� Machine options
and associated equipment will vary�
Machine length: Approximately 1500 mm (excluding
the infeed
Machine width: Approximately 550 mm
Machine height: Approximately 1500 mm
