1.2.9 Machine name plate
The machine name plate (Fig� 1) is located on the side of the electrical cabinet and contains the following informa-
tion:
1 Model: This is the machine model�
2 Machine serial number: This is the number under which the machine data are stored at Bosch�
3 Wiring Diagram: The electrical schematic for the machine�
4 Largest Motor Amps�: This is the maximum amount of amps the drive motor will draw�
5 Short Circuit Interrupt Amps: This is the maximum amps the main circuit breaker can handle�
6 Volts/Hertz/Phase: This is the voltage, frequency and phase required for the machine�
7 Fla/Watt: This is the full load amps or watts the machine can draw��
8 Short Circuit Current Rating: This is the lowest component short circuit rating on the panel�
