Pack201 | Operator Interface | Section 4
EN | 52
© Bosch Packaging Technology, Inc.
All rights reserved 2012
4.8 Screen Messages
Explanation
The following is a list of messages that can be dis-
played on the HMI� Some of these messages are only
displayed if certain options are installed� Whenever
the wrapper is turned ON, the Main Screen appears
and displays any existing conditions, some of which
will prevent the wrapper from running� The wrapper
cannot be started until these conditions are cleared�
Messages
The following messages are displayed when there is
a condition present such as an open guard� Messages
concerning options will not appear unless the machine
is equipped with the option�
Message Action
MACHINE NOT HOMED PRESS THE START BUTTON TO RE-HOME THE MACHINE�
MACHINE NOT IN SYNCHRONIZATION PRESS THE START BUTTON TO SYNCHRONIZE THE MACHINE�
CUTTING HEAD FOLLOWING ERROR�
CHECK THE FEEDBACK� PUSH THE ESTOP BUTTON TO RESET THE
FOLLOWING ERROR OR PRESS START BUTTON TO RUN�
FILM FOLLOWING ERROR�
INFEED FOLLOWING ERROR�
METERING FOLLOWING ERROR�
BACKLOG FOLLOWING ERROR�
ACCUMULATOR FOLLOWING ERROR�
LINESHAFT X FOLLOWING ERROR�
LPF FOLLOWING ERROR�
SIDE CHAIN FOLLOWING ERROR�
GAP X FOLLOWING ERROR�
SIDEBELT FOLLOWING ERROR�
PULLNOSE FOLLOWING ERROR�
POWER FEED ROLL FOLLOWING ERROR�
ROBOT X ARM X FOLLOWING ERROR�
OVERHEAD FOLLOWING ERROR�
OVERHEAD FOLLOWING ERROR LANE X�
VERTICAL CRIMPER FOLLOWING ERROR�
HORIZONTAL CRIMPER FOLLOWING ERROR�
