Pack201 | Operator Interface | Section 4
EN | 13
© Bosch Packaging Technology, Inc.
All rights reserved 2012
4.6.5 Recipe Screen
The Recipe screen allows access to the Functions
screen (1 Figure 10) and the On/Off screen (2 Figure
10)�
• The Functions screen lists all the wrapper param-
eters and displays the current value for each�
• The On/Off screen displays the current status of
various wrapper functions and allows proper level
personnel to turn them on or off�
1 2
Figure 10
