Bosch Rexroth A6VM series 71 User Manual

Bosch Rexroth Corp., RE-A 91610/12.2015
26 A6VM series 71 | Axial piston variable motor
Dimensions size 60
Dimensions [inch (mm)]
▼ Location of working ports on port plates (view Z)
2 SAE working port
A and B at side,
opposite
1 SAE working port
A and B at rear
2 SAE working port
A and B at side, opposite
only HZ7, EZ7/8
1 SAE working port
A and B at rear
only HZ7, EZ7/8
B
A
5.98 (152)
2.13
(54)
6.50 (165)
2.13
(54)
B
A
5.98 (152)
AB
1.48
(37.5)
AB
6.50 (165)
1.48
(37.5)
▼ Splined shaft SAEJ744
S7 ‒ 1 1/4 in 14T 12/24DP
1)
2.20 (56)
DIA4.37 (DIA111)
1.89 (48)
7/16-14UNC-2B
2)
1.10
(28)
DIA1.77
(DIA45)
1.57 (40)
0.37
(9.5)
1) Involute toothing acc. to ANSI B92.1a, 30° pressure angle, flat root,
side fit, tolerance class 5
2) Thread according to ASME B1.1
