Axial piston variable motor | A6VM series 71
Type code
3
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21
A6V M 0 0 / 71 A W V 0 –
2) The settings for the setting screws can be found in the table
(seepages 70 and 71).
Additional function 1
07 Without additional function
0
Additional function 2
08 Without additional function
0
Response time damping (for selection, see control)
09 Without damping (standard with HP and EP)
0
Damping HP, EP, HP5,6D. and EP5,6D., HZ, EZ, HA with counterbalance valve BVD/BVE
1
One-sided in inlet to large stroking chamber (HA)
4
One-sided in outlet from large stroking chamber (DA)
7
Setting range for displacement
2)
10
V
g max
-setting screw
V
g min
-setting screw 060 085 115 150 170 215
Without setting screw
short (0-adjustable)
● ● ● ● ● ● A
medium
● ● ● ● ● ● B
long
● ● ● ● ● ● C
extra long
‒ ● ● ● ● ● D
Short
short (0-adjustable)
● ● ● ● ● ● E
medium
● ● ● ● ● ● F
long
● ● ● ● ● ● G
extra long
‒ ● ● ● ● ● H
Medium
short (0-adjustable)
● ● ● ● ● ● J
medium
● ● ● ● ● ● K
long
● ● ● ● ● ● L
extra long
‒ ● ● ● ● ● M
Series
11 Series 7, index 1
71
Configuration of ports and fastening threads
12 ANSI, port threads with O-ring sealing according to ISO 11926
A
Direction of rotation
13 Viewed on drive shaft, bidirectional
W
Sealing material
14 FKM (fluoroelastomer)
V
Drive shaft bearing
15 Standard bearing
0
Mounting flange 060 085 115 150 170 215
16 SAE J744 127-4
● ● ‒ ‒ ‒ ‒ C4
127-2
‒ ● ‒ ‒ ‒ ‒ C2
152-4
‒ ‒ ● ● ● ‒ D4
165-4
‒ ‒ ‒ ‒ ‒ ● E4
●
= Available
○
= On request
‒
= Not available
