Bosch Rexroth A6VM series 71 - Size 85: Additional Control Variant Dimensions; Size 85 HZ7 Hydraulic Two-Point Control Dimensions; Size 85 EZ7;EZ8 Electric Two-Point Control Dimensions

Bosch Rexroth Corp., RE-A 91610/12.2015
36 A6VM series 71 | Axial piston variable motor
Dimensions size 85
Dimensions [inch (mm)]
▼ HZ7 – Hydraulic two-point control,
negative control
▼ EZ7, EZ8 – Electric two-point control,
negative control
10.47 (266)
1)
9.13 (232)
10.94 (278)
4.41(112)
1.08 (27.5) 1.38 (35)
1)
6.34 (161)
G
X
7.68 (195)
A
B
2.40
(61)
5.20 (132)
G
X
4.88 (124)
G
10.47 (266)
1)
AB
9.13 (232)
10.94 (278)
4.41 (112)
1.08 (27.5) 1.38 (35)
1)
6.34 (161)
G
▼ HA1, HA2 / HA1T3, HA2T3 – Automatic high-pressure-related
control, positive control, with override hydraulic remote con-
trolled, proportional
▼ HA1U1, HA2U2 – Automatic high-pressure-related control,
positive control, with override, electric, two-point
G
M
1
X
G
X
5.98 (152)
11.42 (290)
6.77 (172)
4.45 (113)
M
1
8.15 (207)
1.40
(35.5)
AB
M
1
G
M
1
G
11.42 (290)
9.41 (239)
4.45 (113)
AB
HA1 and HA2, X plugged
HA1T and HA2T, X open
▼ HA1R1, HA2R2 – Automatic high-pressure-related control,
positive control, with override, electric and travel direction
valve, electric
a
b
G
G
B A
4.33
(110)
10.35 (263)
8.86 (225)
4.21 (107)
M
1
M
1
1) Port plate 1 – SAE working ports A and B at rear
