Bosch Rexroth A6VM series 71 User Manual

RE-A 91610/12.2015, Bosch Rexroth Corp.
Axial piston variable motor | A6VM series 71
Dimensions size 150
45
Dimensions [inch (mm)]
▼ Location of working ports on port plates (view Z)
2 SAE working port
A and B at side,
opposite
1 SAE working port
A and B at rear
A
B
8.03 (204)
B
A
3.23
(82)
9.25 (235)
3.23
(82)
▼ Splined shaft SAEJ744
T1 ‒ 1 3/4 in 13T 8/16DP
1)
2.95 (75)
DIA5.35 (DIA136)
1.42
(36)
2.17 (55)
5/8-11UNC-2B
2)
DIA2.36
(DIA60)
2.64 (67)
0.47
(12)
1) Involute toothing acc. to ANSI B92.1a, 30° pressure angle, flat root,
side fit, tolerance class 5
2) Thread according to ASME B1.1
