Axial piston variable motor | A6VM series 71
Installation instructions
73
Above-reservoir installation
Above-reservoir installation means that the axial piston unit
is installed above the minimum fluid level of the reservoir.
Recommendation for installation position 8 (drive shaft
upward):
A check valve in the drain line (cracking pressure 7.5psi
(0.5bar)) can prevent draining of the motor housing.
Installation position Air bleed Filling
5
T
2
T
1
U
F
h
t min
h
min
U (F) T
1
(F)
6
h
t min
h
min
T
2
T
1
U
F
F T
2
(F)
7
T
2
T
1
U
F
h
t min
h
min
F T
1
(F)
8
7.5 psi (0.5 bar)
h
t min
h
min
T
2
T
1
U
F
U T
1
(F)
Note
Port F is not part of the motor and can be provided by
the customer to make filling and air bleeding easier.
