Bosch VIP XD - Specifications; Unit

VIP XD Specifications | en 71
Bosch Security Systems Installation and Operating Manual DOC | V4.0 | 2009.06
9 Specifications
9.1 Unit
Audio Version Only:
Operating voltage 12 to 24 V DC, power supply unit with various primary
adapters included
Power consumption Approx. 7 W
LAN interfaces 1 × Ethernet 10/100 Base-T, automatic adjustment,
half/full duplex, RJ45
Data interfaces 1 × RS-232/RS-422/RS-485, bidirectional, push-in terminal
Alarm inputs 4 × push-in terminals (non-isolated closing contact),
maximum activation resistance 10 Ohm
Relay output 1 × push-in terminal, 30 V
p-p
, 2 A (SELV), 2 contacts
Video outputs 1 × BNC, 1.0 V
p-p
, 75 Ohm, PAL/NTSC
1 × Sub-D 15-pin, VGA/SVGA, 1.0 V
p-p
, RGB analog
Displays 3 × LED (operating voltage, network connection, data
transfer) on rear panel
Operating conditions Temperature: 0 to +50 °C / +32 to +122 °F
relative humidity: 0 to 95%, non-condensing
Approvals IEC 60950; UL 1950; AS/NZS 3548; EN 55103-1, -2;
EN 55130-4; EN 55022; EN 55024; EN 61000-3-2;
EN 61000-3-3; FCC 47 CFR Chapter 1 Part 15
Dimensions (H×W×D) 85×107×26mm / 3.35×4.21×1.02in,
including feet and connections
Weight Approx. 300 g (0.5 lb)
Audio input 1 × 3.5 mm stereo socket
5.5 V
p-p
max., impedance 9 kOhm typ.
Audio output 1 × 3.5 mm stereo socket
3.0 V
p-p
max., impedance 16 kOhm min.
Microphone input 1 × push-in terminal, 2.8 V
p-p
max. at –20 dB,
impedance 2 kOhm typ., supply 2.3 V typ.
Loudspeaker output 1 × push-in terminal, 6 V
p-p
max., RMS 1 W,
impedance 4 Ohm min.
