Bose FreeSpace IZA 190-HZ Service Manual

92
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
ZA 250-LZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C339 470UF, CE, 35V, 20%, RLT, 10X20, 105C, LOW,
ESR
157Q-477M+K-
S9RT
4
C340 1000UF, CE, 35V, 20%, RLT, 12.5X25, 105C, LOW,
ESR
157Q-108M+K-
X&TR
4
C341 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C342 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C343 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C344 47UF, CE, 10V, 20%, RLT, 5X11, 105C 157C-476M+K-IUT 4
C345 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C346 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C347 0.68UF, CM, 100V, 5%, RBT, 7.2X11X6,
METALLIZED
153H-684J+V-NUM 4
C348 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C349 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C350 1000UF, CE, 35V, 20%, RLT, 12.5X25, 105C, LOW,
ESR
157Q-108M+K-
X&TR
4
C351 1000UF, CE, 35V, 20%, RLT, 12.5X25, 105C, LOW,
ESR
157Q-108M+K-
X&TR
4
C352 1000UF, CE, 35V, 20%, RLT, 12.5X25, 105C, LOW,
ESR
157Q-108M+K-
X&TR
4
C353 1000UF, CE, 35V, 20%, RLT, 12.5X25, 105C, LOW,
ESR
157Q-108M+K-
X&TR
4
C354 1UF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C355 1UF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C356 100UF, CE, 25V, 20%, RLT, 6.3X11, 105C, LOW,
ESR
157E-107M+K-
LURT
4
C357 1UF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C358 47UF, CE, 25V, 20%, RLT, P5.0, 5X11, LOW, ESR 157E-476M+K-IUR 4
C359 47UF, CE, 25V, 20%, RLT, P5.0, 5X11, LOW, ESR 157E-476M+K-IUR 4
C361 1UF, CC, 50V, 10%, 0805 150F-105K+J-BD 4
C362 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C364 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C365 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C366 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+
P
-AC 4
C367 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C368 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C369 1000PF, CC, 250V, 5%, 0805 150R-102J+J-BD 4
C370 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C371 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C372 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C373 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C374 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C375 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C376 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C377 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C378 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C379 0.47UF, CC, 25V, 5%, 0805, 1.25X2 150E-474J+J-BD 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
