Bose FreeSpace IZA 190-HZ Service Manual

93
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
ZA 250-LZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C380 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C381 1000PF, CC, 250V, 5%, 0805 150R-102J+J-BD 4
C383 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C384 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C385 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C386 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C387 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C388 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C389 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C390 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C391 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C392 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C393 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C394 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C395 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C396 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+
P
-AC 4
C397 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C398 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C399 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C400 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C401 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C402 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C404 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C406 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C407 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C408 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C409 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C411 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C412 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C413 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C414 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C415 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C416 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C423 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C424 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C425 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C426 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C428 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C436 2200uF, CE, 10V, 20%, RL, 10x20 157C-228M+5-S9 4
C437 100uF, CE, 10V, 20%, R5, 5X11 157C-107M+K-IU 4
C449 330PF, CC, 250V, 10%, YKP, RL, 8.5X8.5 150R-331K+5-PP 4
C450 330PF, CC, 250V, 10%, YKP, RL, 8.5X8.5 150R-331K+5-PP 4
C485 470PF, CC, 50V, 5%, 0603 150F-471J+P-AC 4
C486 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C487 3300PF, CC, 1000V, 10%, RLT, 10X4, X7R, 125C 150N-332K+K-SG 4
C488 3300PF, CC, 1000V, 10%, RLT, 10X4, X7R, 125C 150N-332K+K-SG 4
CX300 0.33UF, CM, 300V, 10%, RB, P15, 18X15.5X10 1511-334K+9-03Z 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
