Bose FreeSpace IZA 190-HZ Service Manual

94
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
ZA 250-LZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
CX301 0.33UF, CM, 300V, 10%, RB, P15, 18X15.5X10 1511-334K+9-03Z 4
XYC301 330PF, CC, 250V, 10%, YKP, RL, 8.5X8.5 150R-331K+5-PP 4
XYC303 330PF, CC, 250V, 10%, YKP, RL, 8.5X8.5 150R-331K+5-PP 4
XYC304 1000PF, CC, 400V, 20%, RL, Y5, U, 9.5X8,
AH09E102MLO
150T-102M+5-RO 4
YC300 1000PF, CC, 400V, 20%, RL, Y5, U, 9.5X8,
AH09E102MLO
150T-102M+5-RO 4

Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L300 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L301 CHOKE-COMMON, MODE, 10MH, 10MH, MIN, AC,
240V, 2A, AL
1806-4037+0000 4
L302 CHOKE-COMMON, MODE, 10MH, 10MH, MIN, AC,
240V, 2A, AL
1806-4037+0000 4
L303 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L304 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L305 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L306 FERRITE, COIL, 22UH, 20%, BL19.2 1807-220M+9 4
L307 CHOKE-COMMON, MODE, 2X16UH, 8A, FT50-43 1806-3913+0 4
L310 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L311 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L313 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L314 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L316 CHOKE-COMMON, MODE, 2X16UH, 8A, FT50-43 1806-3913+0 4
L318 FERRITE, COIL, 22UH, 20%, BL19.2 1807-220M+9 4
L319 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L320 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L321 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L322 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L323 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L324 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L328 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4

Diodes
Reference
Designator
Description
V
endor Part
Number
Note
B300 DIODE, BRIDGE, 800V, 8A, GBU8K, RL 4840-9218+5 4
D300 DIODE, FAST, 800V, 2A, HER207, AT 480
R
-2070+2 4
D303 DIODE, ULTRA, 400V, 16A, MUR1640, TO-220AB,
RB
4801-6400+9 4
D303A FERRITE, BEAD, 26430000101, (FAIR-RITE) 1808-0670+0 4
D304 DIODE, ULTRA, 400V, 16A, MUR1640, TO-220AB,
RB
4801-6400+9 4
D304C FERRITE, BEAD, 26430000101, (FAIR-RITE) 1808-0670+0 4
D305 200V, 0.2A, BAV21W, SOD-123, SMD, PANJIT 480V-21W0+3 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
