Bose FreeSpace IZA 250-LZ

95
ELECTRICAL PART LIST
Diodes (continued)
FreeSpace
®
ZA 250-LZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
D306 LL4148, SM 4804-1480+3 4
D307 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D308 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D309 RECTIFIER, UF4006-T, GI, AT 4840-8530+2 4
D311 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D312 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190+3 4
D314 RECT, 200V, 2A, ER2D, SMB/DO-214AA, SM 480E-R2D0+3 4
DZ300 DZ, 5W, 150V, 5%, AT 483B-1519+2 4
Z300 DZ, 5W, 10V, 5%, 1N5347B, AT, ON 483B-1005+2 4
Z301 DZ, 5W, 13V, 5%, AT 483B-1309+2 4
Z302 DZ, 5W, 13V, 5%, AT 483B-1309+2 4
Z303 DZ, 1/2W, 15V, 5%, SOD-123C, MMSZ5245BT1G 4837-15V9+3 4
Z304 DZ, 1/2W, 30V, 5%, SM 4837-3009+3 4
Z305 DZ, 1/2W, 22VD, RLZTE-1122D, LL-34, ROHM 4837-22D1+3 4
Z306 DZ, 1/2W, 5.6V, SMD 4837-5V69+3 4
Z307 DZ, 1/2W, 12V, 5%, SM 4837-1209+3 4
Z308 DZ, 1/2W, 12V, 5%, SM 4837-1209+3 4

Transistors
Reference
Designator
Description
V
endor Part
Number
Note
Q300 2N2222, SMD, MMBT2222ALT1G 4860-5410+3 4
Q301 MOSFET, N-CH, 60V, 115MA, 2N7002, SOT-23, SM 4907-0020+3 4
Q302 MMBT3906LT1G, SMD 4860-1980+3 4

Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
U300 PWM, CONTROLER, TOP258YN, TO-220-7C, PI 3132-7241+0-35 4
U301 SENSOR, PHOTOCOUPLER, EL817, EVERLIGHT 481E-L817+3 4
U302A TR, TIP31CTU 4860-2620+5 4
U303 AMP, TDA8920BTH, SOT566-3 3132-2641+1 4
U304A PNP, TIP32C, HFE:10-50, TO-220RL 485I-P32C+5 4
U305 REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-7691+0-16 4
U306 REGULATOR, NJM7805DLA, TO-252 3132-7310+0 4

