Bose FreeSpace IZA 250-LZ

96
ELECTRICAL PART LIST
Miscellaneous
FreeSpace
®
ZA 250-LZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
CN1 CONNECTOR, 2P, P3.96, STRAIGHT, M 2101-2780+0 4
CN2 CONNECTOR, 2P, P3.96, STRAIGHT, M 2101-2780+0 4
FUS1 FUSE, T5A, 250V, 8X8.5, VDE/, PSE/CCC, RLT,
LITTELFUSE
5120-1144+0-L 3,4
HS1 HEATSINK, INNER, 56X28X30, AL-EXT 5401-0271+0 4
HS1A SCREW, M3X6, BINDING, (BLK) 2904-3006+3000 4
HS1B SCREW, M3X6, BINDING, (BLK) 2904-3006+3000 4
HS2 HEATSINK, (214), 20MM-HIGH, HOLE 5400-0831+0 4
HS2A SCREW, B-TITE, PH, M2.6X, 6, MM, BZ, CROSS 2950-2606+3000 4
HS2B SCREW, 3X8, TAPPING 2950-3008+3000 4
HS3 HEATSINK, (214), 20MM-HIGH, HOLE 5400-0831+0 4
HS3A SCREW, B-TITE, PH, M2.6X, 6, MM, BZ, CROSS 2950-2606+3000 4
HS3B SCREW, 3X8, TAPPING 2950-3008+3000 4
J1 CONNECTOR, WAFER, 2P, P7.92, STRAIGHT 2101-3092+0 4
J4B CONNECTOR, 11P, ST, WAFER, P=2.0 2102-110S+003 4
J109A CONN, 2P, WAFER, P2.0, ST, 25055440, CT, AM
P
2101-1424+0 4
RV1 SURGE, PROTECTOR, 270V, 4500A, D15,
THINKING
2706-0003+0 3,4
RV2 SURGE, PROTECTOR, 270V, 4500A, D15,
THINKING
2706-0003+0 3,4
T1 TRANSFORMER, SW, IN80-288V, OUT+/-28V,
50X2, 35X42, ER
1806-4131+0000 3,4
TH300 NTC, THERMISTER, 50HM, 4A, NIOSP005L,
UL/CSA/VDE
5202-0010+0 3,4
U302B HEATSINK, FOR, 7805, 2438-17 5400-9130+0 4
U302C SCREW, 3X8, TAPPING 2950-3008+3000 4
U302D SCREW, B-TITE, PH, M2.6X, 6, MM, BZ, CROSS 2950-2606+3000 4
U302E INSULATN, MICA, T-400, 8302, 18X12.7M, , T0220 3100-8040+0 4
U302F BUSHING, TO-220A 4152-6830+0 4
U304B HEATSINK, FOR, 7805, 2438-17 5400-9130+0 4
U304C SCREW, 3X8, TAPPING 2950-3008+3000 4
U304D SCREW, B-TITE, PH, M2.6X, 6, MM, BZ, CROSS 2950-2606+3000 4
U304E INSULATN, MICA, T-400, 8302, 18X12.7M, , T0220 3100-8040+0 4
U304F BUSHING, TO-220A 4152-6830+0 4

