Setting up the System
Installing the amplifier
Place the amplifier on a sturdy surface, close to an AC (mains) power source.
Tip: For wall mounting instructions, see page 25.
The amplifier does not need to be close to your speakers.
Installation guidelines
Amplifier
Placement
• Place the amplifier on a shelf or mount it on a wall.
• Install the amplifier indoors, close to an AC (mains) power outlet.
CAUTIONS:
• Place the amplifier in an area where the maximum ambient tempera-
ture is less than 104°F (40°C).
• For optimum performance, place the amplifier in a well-ventilated area.
• DO NOT place the amplifier in a completely enclosed area.
If adequate ventilation is not provided, performance of the system
may be reduced.
• Place the amplifier with a minimum of 3 in. (75 mm) of ventilation
around it.
• Do not stack multiple amplifiers on top of each other. If using multiple
amplifiers, place them side by side.
Wall Mounting
• Use the provided mounting bracket and hardware (see page 25).
• Vertical mounting: attach the amplifier to the bracket with the
Wi-Fi
®
indicator at the bottom; connector panel at the top.
• Horizontal mounting: attach the amplifier to the bracket with connector
panel on the left or right.
• DO NOT mount the amplifier on the ceiling.
Speaker
Connections
CAUTIONS:
• Use only unpowered speakers. DO NOT connect any make or model
of powered speakers. Doing so may cause damage to the equipment.
• One pair of speakers requires 4 ohm minimum each.
• Two pairs of speakers require 8 ohm minimum each.
Speaker wire recommendations
Maximum Length Gauge
30 ft. (9 m) 18 (0.82 mm
2
)
45 ft. (14 m) 16 (1.3 mm
2
)
70 ft. (21 m) 14 (2.0 mm
2
)
Placing the speakers
Place the speakers in their permanent location before connecting the speaker wires
to the amplifier.
