Bostitch N89C User Manual

-7-
FASTENER DEPTH CONTROL ADJUSTMENT
T
he Fastener Depth Control Adjustment feature on this tool provides control of the nail drive depth from flush
with or just above the work surface to shallow or deep countersink.
TO ADJUST THE FASTENER DEPTH CONTROL:
Disconnect tool from air supply before attempting any parts disassembly and before
changing the work contacting element adjustment.
1. Push in on locking button.
2
. Adjust contact arm up to increase depth
o
f drive or down to decrease it.
3. Release locking button
DIRECTIONAL EXHAUST DEFLECTOR
The adjustable exhaust deflector can be rotated into any desired position by hand without the use of any tools.
2. ADJUST
1. PUSH IN
3. RELEASE
LOCKING BUTTON
C
ONTACT ARM
Exhaust Deflector

Bostitch N89C Specifications

General

Type	Coil Nailer
Magazine Capacity	300 nails
Operating Pressure	70-120 PSI
Power Source	Pneumatic
Fastener Type	Coil nails
Nail Diameter	0.131 inch (11 gauge)
