32 Using Your Printer
ADVANCED SETUP
MAINTENANCE
TEST PRINT
CURRENT CONFIG
DATABASE CONFIG
TEST RIBBON
TEST PATTERN
• Prints a configuration test label of current selections
• Prints a configuration label of default menu selections
• Test reflects the status of the ribbon type
• Prints label with a test pattern (to check dot elements)
FRONT PANEL
LED TEST
KEYPAD TEST
DISPLAY TEST
• Exercises the front panel indicator LEDs
• Checks the operation of the front panel keypad
• Exercises the front panel LED display
TEST I/O
MONITOR GP INPUT
TEST GP OUTPUT
SENSOR READINGS
DIGITAL SENSORS
• Allows monitoring of the General Purpose Input
• Allows testing of the General Purpose Output
• Displays the status of the digital and analog sensors
• Displays digital sensors with active values below them
HD = Head
CT = cutter
LP = label present
RS = ribbon saver
D=Down
D=Down
Y=Blocked
D=Down
U=Up
U=Up
N= Not Blocked
U=Up
ANALOG SENSORS
• Displays 4 analog sensors with sensor values below each
THR = Thermal RF* = reflective TOF mode
RIB = Ribbon motion TR* = Transmissive
(* only the active mode is displayed)
SERIAL LOOPBACK
SERIAL PORTA
• Serial loopback connector must be installed for test
• Initiates test (see Self-Test, Section 3.3.)
INSTALLED OPTION
CUTTER
RIBBON SAVER
• Lists options
* = installed
ADVANCED SETUP
MODULES
• The optional modules are available
Module Slot A − External Flash
PRINT DIRECTORY
PRINT FILE
COPY MODULE
TEST MODULE
FORMAT MODULE
• Prints contents of selected memory modules
• Prints label, font, or image from selected module
• Copies data from one module to another
• Tests Read/Write operation of selected modules
• Formats the selected memory modules
