Manual for BL-819, BL-830, BL-875
V6.1
© Copyright Brainboxes Ltd Page 38 of 40
13. Technical Specifications
Qualified Output Power: > 0 dBm < +4.0 dBm @ 25 oC Receive sensitivity Single Slot = -83 dBm with 0.1% BER
13.1. Storage and Operating Environment
13.1.1. Storage
Temperature: -10
o
C to +60
o
C
Humidity: 8% to 95% non-condensing
13.1.2. Operational
Temperature : 0
o
C to +40
o
C
Humidity : 20% to 75% non-condensing
13.2. Power requirements
13.2.1. Input Voltage Requirements
The product was qualified using a fully rectified AC/DC power supply supplying 550mA @ 5V. To ensure your product
performs within the regulatory requirements, it is recommended that you use the AC/DC adapter supplied... For your
information only, the voltage range is given below. Minimum 5.0 V – Maximum 13.6 VDC NOTE: Power supplied through Pin 9
of the RS 232 connector does go through the regulator and has the same input requirements as the DC jack, +5.0 to 13.6 VDC.
13.3. Chipset
The chipset used in the BL-819/830 is the Bluecore BC02 BC212015B.
BlueCore2-External is a single chip radio and baseband IC for Bluetooth 2.4GHz systems. It is implemented in 0.18μm CMOS
technology. When used with external flash containing the CSR Bluetooth software stack, it provides a fully compliant
Bluetooth system for data and voice communications.
The Bluecore BC02 BC212015B chip has these features:
• Low power 1.8V operation
• Small footprint in 96-ball VFBGA and LGA packages (6x6mm 8x8mm and 10x10mm)
• Fully qualified Bluetooth component
• 0.18μm CMOS technology
• Full speed Bluetooth operation with full piconet support
• Support for 8Mbit external flash
• Minimum external components
