CHAPTER 6 HYDRAULIC SYSTEM
6
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
4.9 HYDRAULIC FILTER AND STRAINER
4.9.1 HYDRAULIC FILTER
7UDQVPLVVLRQVLGH
*HDUSXPSVLGH
F42W633A
T h e h y d r a u l i c f i l t e r i s i n s t a l le d u nd e r t he
transmissiontolteroilintheoiltank(transmission)
before this oil is delivered to the gear pump.
Hydraulicoilisownthroughtheholeonthetopof
theoilltercartridgeandispassedfromtheoutside
totheinsideofthelter.Then,itisowedinthrough
the hole in the middle of the cartridge.
'JMUFSFMFNFOU
'JMUFSFMFNFOUIPMFPGUPQ
K20W622A
Filtering area 4,972 cm
2
Number of folds 55
Folding width 195
×
17
×
55 folds
Bursting strength 4.5 bar
Max.neness 110
±
8
µ
Min.neness 92
±
8
µ

Hydraulic filter replacement: after initial 50
hours, and then every 300 hours of use
Notes
FILTER ELEMENT SPECIFICATIONS
▶
